Less Power That Gives You More.

The JT400 platform can deliver more data, more often, with no external power.

No trenches. No wires. No kidding.

About FlowWorx

FlowWorx Energy specializes in developing innovative technologies for the natural gas and oil industries. Our roots stem from Newgate Instruments, an East Grandby, Connecticut-based company that was launched by industry-leading engineers in 2012. Since acquiring and re-branding Newgate Instruments in 2019, FlowWorx has set out to meet the unique needs of energy companies that require low power, wireless technologies without the loss of reliability or accuracy.

What Sets Us Apart

ULTRA-LOW
POWER
CONSUMPTION: 4 mW

Best-in-class performance in a fully wireless configuration!

Up to 3.5 years estimated autonomy.

INDUSTRY-LEADING ACCURACY, RIGHT OUT OF THE BOX

Today’s operations demand accuracy and performance. We believe customers shouldn’t have to pay extra for it.

EXTERNAL
DEVICE
CONNECTIVITY

(9) Total I/O points, including RTD, Analog Inputs and User-Configurable DI/DOs.

WIRELESS COMMUNICATION CAPABLE

ISM Band Radio Connectivity

Cellular Modem in Development

Simplify your Installation with the JT400.

COMPETITOR REMOTE INSTALLATION

Standard Multivariable Transmitters (MVTs) generally require 10-12 mA of current to operate plus additional current during communication. They cannot log data. For API compliant measurement, additional equipment is needed to log data and control an external radio and solar charging system. These additional components are often not suitable for Class I Div 1 locations and require trending to be placed in a safer area.

JT400 PLATFORM INSTALLATION

The JT400 integrates the MVT, power system and radio antenna. Low power operation allows enough energy to be scavenged from indirect sunlight by an internal solar panel to power the whole system. Unlike typical transmitters, the JT400 has data logging and time-stamping capabilities that allow API-compliant once-per second measurement with 15-minute averaging of variables plus extensions. The explosion-proof housing doubles as an antenna. Just rotate the display towards the receiving RTU for 1000-ft LOS range.

Product Highlights

Click on each icon to read more about the functionality of the JT400.

Meet the Team

MATT RAGLIN

CEO

PAUL MAYER

President

RICHARD MESSER

General Manager

MARK ROLLINS

Firmware Development Engineer

LINDSEY JONES

Marketing Director

Reach out, we’re here to help!
